"CONTROLLED ACCESS TECHNOLOGY"
A complete access control system expandable to 16 doors and 255 relay points for control of elevators, HVAC, lights or other facility control applications that require activation or monitoring. Capacity of up to 16,200 cards, 2700 Phone numbers, 16 time zones, 16 Access levels and 16 access groups. Program with “SELCOM” software (Windows XP, Vista, 7,and 8 in their 32/64 bit versions) via internet or local using the built in modem or IP (NIC), RS232 or wireless. Available with 2, 4, or 10 line LCD display. All systems come with 2 relays (standard) and board level surge suppression at no additional cost.
CAT 2 (2 Line Display) | ||
Model# | Phone capacity |
Card capacity |
CAT2HF50 | 50 | 300 |
CAT2HF125 | 125 | 750 |
CAT2HF250 | 250 | 1500 |
CAT2HF500 | 500 | 3000 |
CAT2HF2700 | 2700 | 16200 |
CAT 4 (4 Line Display) | ||
Model# | Phone capacity |
Card capacity |
CAT4HF50 | 50 | 300 |
CAT4HF125 | 125 | 750 |
CAT4HF250 | 250 | 1500 |
CAT4HF500 | 500 | 3000 |
CAT4HF2700 | 2700 | 16200 |
CAT 10 (10 Line Display) | ||
Model# | Phone capacity |
Card capacity |
CAT10HF50 | 50 | 300 |
CAT10HF125 | 125 | 750 |
CAT10HF250 | 250 | 1500 |
CAT10HF500 | 500 | 3000 |
CAT10HF2700 | 2700 | 16200 |
Above: CAT10 with OPTDF1 (Designer Door Frame)
Enhance the capabilities of the CAT Series with our
CAT Expansion Modules Model: CATDR4 (Card Access)
and Model: CATRL8 (Relay) for control of Elevators, HVAC, Lights
or other facility control applications
DOWNLOAD MANUALS
DOWNLOAD PRODUCT INFORMATION
• CAT 10, 4 and 2 Product Sheet
DOWNLOAD A&E SPECIFICATIONS
EXPANSION MODULES
The CAT Card Reader and Relay Expansion Modules are designed to provide greater capability and flexibility to the CAT Series. Use of these modules can expand the standard CAT or CAT Card units to control up to16 doors ( 3 CATDR4’s card reader modules) and 255 relay points ( 32 CATRLY8 relay modules) for applications such as control of elevators, HVAC, lights or other facility control points that require activation or monitoring. (CAT /CAT Card unit must have CATRS485CONVKIT installed).
This capability in addition to having up to 16,200 cards (with individual names), 16 time zones, 16 Access levels and 16 access groups meets a wide variety of applications.
Used with the intuitive latest “SELCOM” software it can be easily programed and monitored via modem or the option IP NIC card. This software has made the CAT series compatible with Windows Vista, 7, 8 and 10 in their 32/64 bit versions.
CATDR4 Provides reader expansion of ANY CAT or CAT Card systems. The wire distance from CAT to the farthest expansion module:
4000 feet. 3 MAX. PER CAT system.
CATRLY8 Provides relay expansion of ANY CAT or CAT Card system. The wire distance from CAT to the farthest expansion module:
4000 feet. Up to (32) CATRLY8 Modules per CAT system.
